These stainless steel couplings are interchangeable with the “Snap-Tite” type. The stainless steel couplings and adapters simplify the connection of spray guns to hoses, lances and any other components.
COUSB1/2-M, “Snap-Tite” coupler
Description
Additional information
| Version |
"Snap-Tite" compatible |
|---|---|
| Connection |
1/2" BSP male |
| Material body |
Stainless steel (AISI 303) |
| Material of the spring & locking ring |
Stainless steel (AISI 301) |
| Material of the balls |
Stainless steel (AISI 420) |
| Material of the seals |
FKM (FDA) |
| Maximum pressure (bar) |
200 |
| Temperature range (°C) |
-20 / +100 |
| Weight (kg) |
0 ,167 |
| HS-code |
73072910 |
